Travel Limit Switch
ME series travel limit switch is an electrical component used in control circuit, is mainly used to limit the position or travel of mechanical movement, to achieve automatic stop, reverse movement, variable speed movement or automatic round trip movement.
Send Inquiry
Add To Inquiry
Product Introduction
Introduction:
ME series travel switch is mainly used for automatic control of machine tool machinery and program control in the circuit with rated voltage of AC 50Hz(60Hz) to 380V or DC voltage to 220V current 5A.
Technical parameter:
| Product name | Travel switch | Shell material | Flame retardant material |
| Product model | ME series | Contact form | 1 Normally open. 1 Normally closed |
| Voltage and current | 250VAC/5A,115VDC/0.4A | Action form | self-resetting |
| Connection mode | Platen type | Ambient temperature | -5℃~40℃ |
| Model number | structure |
 |
Model: ME-8108 Structural features: adjustable roller swing rod |
 |
Model: ME-8104 Structural features: roller rotating arm |
 |
Model: ME-8107 Structural features: adjustable rod type pendulum rod |
 |
Model: ME-9101 Structural features: universal spring type III |
 |
Model: ME-8111 Structural features: direct pressure plunger type |
 |
Model: ME-8112 |
| ME-8122 | Model: ME-8122 Structural features: straight pressure vertical roller |
| ME-8166 | Model: ME-8166 Structural features: universal spring type I |
Wiring diagram
